Digicept Emcee ELF

Emcee Lite Form Factor	A master performer for your network, Digicept Emcee ELF offers multiple applications and enhanced services in a single platform for circuit and packet-switched networks. Whether your goal is generating revenue, providing enhanced services, implementing custom applications, or any combination thereof, ELF provides the architecture to meet your network needs.

Architecture | Administration | Application Future-ability
Sample Messages | Specifications

Open Architecture = Flexibility
ELF keeps pace with the various interface options and an open architecture. Interfaces and applications are available for T1, E1, and ISDN/PRI networks. Additionally, ELF’s open-standard PCI® architecture and Windows® 2003 operating system provide the path to future capabilities and applications.

Ease of Administration
Several features make for easy management of ELF in local or remote networks. A browser-based interface gives administrators a familiar, intuitive way to navigate through menus. Multiple remote systems can be administered from a central location. Conversely, multiple users can administer a single system from remote locations.

Every ELF is equipped with RAID hard drives.

The ELF can support a span interface (T1, E1) card that can be equipped to handle a single (1) span, a double (2) span, or a quad (4) span card.

One Platform, Multiple Applications
Incorporating a variety of applications in one platform makes ELF a space and money-saving solution. The possibilities for configuring a system are virtually unlimited. ELF grows with your network; additional applications are typically installed through software, rather than hardware modifications.

Unlimited Potential
Got an idea for that GREAT application? ELF’s architecture presents limitless opportunity for building applications that establish brand/company identity, generate revenue, and offer network solutions. In a competitive and converging network, ELF performs time and again in a variety of unique environments and challenging situations.

Your imagination is the limit when exploring the myriad of applications ELF can offer. Below represents applications that are current and future ELF capabilities.

AIN/WIN
Audiotex
Auto attendant
ANA
Branding
Continuous
Broadcast
Call return (*69)
Changed number / Referral
Call Completion
Multiple Referrals
CLASS I and II
Equal access
FLEX
POTS
Reminder service
Time, temperature and weather
TTY intercept
Voice mail
Wake-up service
—with time, temperature and weather

Specifications

Enclosure	16.0" W x 13.0" D x 3.67" H Front mount or 4.5" offset. 19", 21", 23" standard mount. Adaptors available for other sized racks.
Power Requirements	-40 VCD to -60 VDC, -48 VCD inputs nominal, 5A maximum, 2A typical.
Cooling	Unit has internal fan cooling with alarms and removable filter. It is not necessary to allow air space above and below enclosure.
Operating Temperature	10° to 40°C (50° to 104° F)
Relative Humidity Non-Condensing	10% to 80%
Interfaces	T1, E1, ISDN/PRI, Ethernet (10/100 Mb)
Signaling and Protocols	SMDI, MFR1, MFR2, DTMF
Architecture	PCI^®
Operating System	Windows^® 2003
Processor	Pentium^® technology
Memory	1 GB standard
Hard Drive	160 GB SATA RAID
USB Ports	4 (2 front, 2 back)
Backup Software	Optional with flash drive and loaded SATA hard drive.
MTBF	Disk Drive: 1,200,000 hours
Design Compliances	NEBS, FCC Part 15 and 68, UL1950, R1129/1129+, Q.920, Q.921, Q.930, Q.931, Q.932
